Frame Construction |
4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated |
---|---|
Fork Construction |
4130 Chromoly, Natch tubing, double-butted tapered fork blades, brazed lugs, ED coatedVertical |
Rear Dropout Configuration |
Vertical |
Rear Hub Spacing |
10 x 135mm |
Front Hub Spacing |
10 x 100mm |
Rear Brake |
Disc - 51mm I.S. (160mm max rotor) |
Front Brake |
Disc - 51mm I.S. (160mm max rotor) |
Head Tube |
Ø34mm |
Steerer Tube |
Ø28.6mm (1-1/8") |
Crown Race |
Ø30mm (1-1/8") |
Stock Headset Upper (S.H.I.S.) |
EC34/28.6 |
Stock Headset Lower (S.H.I.S.) |
EC34/30 |
Seat Collar |
Ø30mm |
Seatpost |
Ø27.2mm |
Front Derailleur (Clamp) |
Bottom-pull (Ø28.6mm) |
---|---|
Max Chainring (CL)[3] |
1x (Road): 44T 2x (Road): 42/53T 3x (Road): 38/52/56T |
Bottom Bracket |
68mm threaded (1.37" x 24TPI) |
Tire Clearance Frame [1]/[2] |
26in: 26 x 2.1" (with or without fenders) 700c: 700c x 42mm (w/ fenders) 700c: 700c x 45mm (w/o fenders) |
Tire Clearance Fork [1] |
26in: 26 x 2.0" (with or without fenders) 700c: 700c x 50mm (with or without fenders) 700c: 29 x 2.0" (with or without fenders) |
Rigid Fork Spec |
26in: 376 x 45mm 700c: 390 x 45mm |
Max Suspension Fork Length [4] |
N/A |
Bottle Mounts Frame |
3 Standard |
Bottle Mounts Fork |
N/A |
Rack Mounts Frame |
Yes (upper and lower threaded) |
Rack Mounts Fork |
Yes (upper, lower, and mid-blade threaded) |
Fender Mounts Frame |
Yes |
Fender Mounts Fork |
Yes |
Other Features |
Chainstay mounted spoke holder |
